LPA5168HVS
5.15-6.875GHz,V2, 4X4 MIMO, V & H Pol, 90 °(-6dB)/ 60 ° (-3dB), 18dBi Sector Antenna
|
LPA5168HVS is a four-port, dual pol, 90 degree (-6dB)/ 60 degree(-3dB) wideband sector antenna working at 5.15-6.875GHz. It is designed for WiFi 7 and future use, and almost half size compared to V1 antenna of LinQ.
Features
● A single antenna covers 5.15-6.875GHz. ● 18dBi gain to cover long distance. ● Compact size to help deploy networks easily.
|
| NAME | TYPE | SIZE |
| LPA5168HVS_datasheet.pdf | 1.78MB |
|
